Home MSI SPATIUM M480 PRO PCIe 4.0 NVMe M.2 1TB SSD, 1GB DDR4, Sequential Read up to 7400MB/s, Sequential Write up to 6000MB/s, 700 TBW, 5 Year Warranty
MSI SPATIUM M480 PRO PCIe 4.0 NVMe M.2 1TB SSD, 1GB DDR4, Sequential Read up to 7400MB/s, Sequential Write up to 6000MB/s, 700 TBW, 5 Year Warranty
MSI SPATIUM M480 PRO PCIe 4.0 NVMe M.2 1TB SSD, 1GB DDR4, Sequential Read up to 7400MB/s, Sequential Write up to 6000MB/s, 700 TBW, 5 Year Warranty
MSI

MSI SPATIUM M480 PRO PCIe 4.0 NVMe M.2 1TB SSD, 1GB DDR4, Sequential Read up to 7400MB/s, Sequential Write up to 6000MB/s, 700 TBW, 5 Year Warranty

In stockSKU: HBM-SPATIUMM480PRO-1TB
$376.20
$376.20

MSI SPATIUM M480 PRO PCIe 4.0 NVMe M.2 1TB SSD, 1GB DDR4, Sequential Read up to 7400MB/s, Sequential Write up to 6000MB/s, 700 TBW, 5 Year Warranty

BrandMSI
Manufacturer part numberSPATIUM M480 PRO PCIe 4.0 NVMe M.2 1TB
Model NameSPATIUM M480 PCIe 4.0 NVMe M.2
Capacity1TB
ControllerPHISON E18
Flash Memory3D NAND
Dram Cache1GB DDR4
Form FActorM.2 2280
InterfacePCIe Gen4x4, NVMe 1.4
CompatibilityPCIe Gen4 / Gen3 / Gen2 / Gen1
Dimensions80.00mm (L) x 22.00mm (W) x 2.15mm (H)
Sequential Read up to (MB/s)7400
Sequential Write up to (MB/s)6000
Random Read 4KB up to (IOPS)750,000
Random Write 4KB up to (IOPS)1,000,000
Maximum Operating Power (W)9.5
Idle Power PS3 (mW)40
Low Power L1.2 (mW)3
Operating Temperatures0°C – 70°C
Storage Temperatures-40°C – 85°C
Terabytes Written (TBW)700
Mean Time Between Failure (MTBF)Up to 1,600,000 Hours
Limited Warranty5 Years, or the coverage for the maximum TBW as stated, whichever comes first.
Advanced FeaturesTRIM (Performance Optimization, OS support required)
SMART (Self-Monitoring, Analysis and Reporting Technology)
LDPC (Low Density Parity Check) ECC Algorithm
End to End Data Path Protection
APST (Autonomous Power State Transition)
AES256/Pyrite (Encryption, Data Security)
