Gigabyte UD750GM ICE PG5 750W ATX PSU Power Supply 80+ Gold >90% Black Flat Cables Single +12V Rail Japanese >100K Hrs (NEW)
Features
- Ultra Durable
- Support PCIe Gen 5.0 graphics cards
- Support Intel ATX 3.0 standard
- 80 PLUS Gold certified
Specifications
| Model | |
| GP-UD750GM PG5 | |
| PFC | |
| Active PFC (>0.9 typical) | |
| Input Voltage | |
| 100-240 Vac (full range) | |
| Input Current | |
| 12-6A | |
| Input Frequency | |
| 60-50 Hz | |
| Output Capacity | |
| 750W | |
| Dimension | |
| 150 x 140 x 86mm | |
| Fan Type | |
| 120mm Hydraulic Bearing(HYB)fan | |
| 80 PLUS | |
| Gold | |
| Efficiency | |
| 90% at typical load | |
| MTBF | |
| >100,000 hours | |
| Protection | |
| OVP/OPP/SCP/UVP/OCP/OTP | |
| Power Good Signal | |
| 100-150ms | |
| Hold Up Time | |
| >16ms | |
| Cable Type | |
| Flat, All black | |
| Connectors | |
| ATX/MB 20+4 Pin x 1 | 610mm*1 |
|---|---|
| CPU/EPS 4+4 Pin x 2 | 600mm+200mm*1 |
| PCIe 16 Pin x 1 | 700mm*1 |
| PCIe 6+2 Pin x 4 | 600mm+150mm*2 |
| SATA x 8 : | |
| 600mm+150mm+150mm+150mm*2 | |
| 4 Pin Peripheral x 3+4-Pin floppy x 1 | 500mm+120mm+120mm+150mm*1 |
